SKY2000-EO GAS DETECTOR

Product Model: SKY2000-EO

SKY2000-EO Ethylene oxide gas detector is a kind of fast response and high accuracy gas measurement portable device. With internal sampling pump, fast sampling speed and high flow rate, ensuring the response time of the detector. Unique design, small size and easy to carry with. Special high intensity engineering plastics housing, suitable for different kinds of situation and environment. We dedicate to provide you the most reliable, accurate and the safest solution of gas detection.

Send Us Inquiry Now

Key Features

Fast response & high accuracy

– with internal sampling pump, response time ≤30s

– using world top brand sensors, high precision, the detection result is approved by the third testing organization

Comprehensive functions

– gas concentration unit PPM and mg/m3 can be shifted by one press.

– With Self-calibration and zero calibration functions, making the detection more accurate and reliable.

– One press to restore factory setting, free from the bother of mis-operation

Alarm mode

– Alarm with light, sound and vibration, ensuring the safety of the users.

– Alarm point is settable according to the specific requirements.

Data logging

– Storage capacity of over 100000 sets, the historical detected data can be read on the detector quickly.

– High-speed data transmission by USB, available for data downloading to PC.

Long operation time

– High capacity of lithium polymer rechargeable battery, for toxic gas: 14h continuously. For combustible gas: 10 h continuously.

High quality case

– Special high intensity engineering plastics housing, suitable for different kinds of situation and environment

– IP65 protection degree, water-proof, dust-proof, explosion-proof

Industry

Application: farms, livestocks, liquid ammonia plants, public toilets, septic tanks.

Specification

Sampling	With internal sampling pump, flow rate is up to 1L/min
Data logging	Data logging with adjustable interval, and available for data downloading to PC through USB cable.
Gas	Ethylene oxide EO
Measure Range	0-10ppm, 0-50ppm,0-100ppm,0-200ppm, 1000ppm (measure range can be customized)
Resolution	0.01ppm,0.1ppm,1ppm(resolution can be customized)
Precision	≤±2%F.S. (higher precision is available)
Response Time	≤10S
Zero shift	≤±1%（F.S./year）
Display	LCD dot matrix display, with display of gas type, real time gas concentration, battery power, time, gas unit.
Temperature	-20℃～50℃
Humidity	0-95%RH (non-condensing)
Explosion-Proof	ExibⅡCT4
Degree of protection	IP65
Alarm	Sound: 85dB Light: LED, low alarm: blue, high alarm: red Vibration: the detector will vibrate when powered on Alarm point is settable according to customer requirement.
Battery	3.6V 2300mAh lithium polymer rechargeable battery, operate time is about 12h continuously, charging time: 4-6 h
Dimensions	205x75x32mm
Weight	300g
Approval	CE, CNEX explosion proof certificate, CMC(China Metrology Certification)
Warranty	12 months

Gases and Ranges

Gas	Range	Other available range	Resolution
CO	0-1000ppm	0-100ppm, 0-500ppm, 0-2000ppm, 0-5000ppm, 0-10000ppm	0.1ppm, 1ppm
H2S	0-100ppm	0-10ppm, 0-50ppm, 0-500ppm, 0-1000ppm, 0-10000ppm	0.01, 0.1, 1ppm
O2	0-30%VOL	0-5%VOL, 0-25%VOL, 0-50%VOL, 0-100%VOL	0.01%VOL
EX / CH4	0-100%LEL	0-100%VOL	1%LEL, 0.01%VOL
N2	0-100%VOL		0.01%VOL
NH3	0-100ppm	0-50ppm, 0-500ppm, 0-1000ppm, 0-5000ppm	0.01, 0.1, 1ppm
CL2	0-10ppm	0-20ppm, 0-50ppm, 0-100ppm, 0-200ppm, 0-500ppm	0.01. 0.1ppm
H2	0-1000ppm	0-100%LEL, 0-2000ppm, 0-10000ppm, 0-40000ppm, 0-4%VOL	1%LEL, 1ppm
CH2O	0-10ppm	0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm	0.01, 0.1, 1ppm
O3	0-50ppm	0-1ppm, 0-10ppm, 0-20ppm, 0-100ppm, 0-500ppm, 0-1000ppm	0.01, 0.1, 1ppm
CO2	0-5000ppm	0-2000ppm, 0-10000ppm, 0-20000ppm, 0-50000ppm, 0-5%VOL, 0-10%VOL, 0-50%VOL, 0-100%VOL	1ppm, 0.01%vol
NO	0-100ppm	0-20ppm, 0-50ppm, 0-500ppm, 0-1000ppm, 0-4000ppm	0.01, 0.1, 1ppm
NO2	0-20ppm	0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-4000ppm	0.01, 0.1, 1ppm
NOX	0-20ppm	0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-4000ppm	0.01, 0.1, 1ppm
SO2	0-10ppm	0-20ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-2000ppm	0.01, 0.1, 1ppm
ETO	0-10ppm	0-20ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm	0.01, 0.1, 1ppm
PH3	0-10ppm	0-20ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-5000ppm	0.01, 0.1, 1ppm
HCL	0-10ppm	0-20ppm, 0-50ppm, 0-100ppm	0.01ppm
HCN	0-10ppm	0-20ppm, 0-50ppm, 0-100ppm	0.01ppm
COCL2	0-1ppm		0.01ppm
CLO2	0-10ppm	0-20ppm, 0-50ppm, 0-100ppm	0.01ppm
SiH4	0-10ppm	0-50ppm	0.01ppm
F2	0-10ppm	0-1ppm	0.01ppm
HF	0-10ppm		0.01ppm
HBr	0-10ppm	0-50ppm, 0-100ppm	0.01ppm
H2O2	0-100ppm	0-500ppm, 0-1000ppm, 0-2000ppm	0.01, 0.1, 1ppm
B2H6	0-5ppm	0-10ppm	0.01ppm
AsH3	0-1ppm	0-10ppm, 0-50ppm	0.01ppm
GeH4	0-1ppm		0.01ppm
N2H4	0-1ppm		0.01ppm
THT	0-100ppm	0-50mg/m3, 0-100mg/m3	0.01ppm, 0.01mg/m3
Br2	0-5ppm	0-10ppm, 0-50ppm	0.01ppm
C2H2	0-100ppm	0-2.3%VOL	0.01ppm, 0.01%VOL
C2H4	0-10ppm	0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 2.4%VOL	0.01, 0.1, 1ppm, 0.01%VOL
CH3OH	0-100ppm	0-50ppm, 0-500ppm, 0-1000ppm	0.01, 0.1, 1ppm
C2H5OH	0-100ppm	0-50ppm, 0-500ppm, 0-1000ppm	0.01, 0.1, 1ppm
CH4S	0-100ppm		0.01ppm
C8H8	0-10ppm	0-50ppm, 0-100ppm, 0-1000ppm, 0-5000ppm, 0-10000ppm	0.01, 0.1, 1ppm
C4H6	0-10ppm	0-50ppm, 0-100ppm, 0-1000ppm, 0-5000ppm, 0-10000ppm	0.01, 0.1, 1ppm
VOC/TVOC	0-10ppm	0-1ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-5000ppm, 0-10000ppm	0.001, 0.01, 0.1, 1ppm
CH3Br	0-10ppm	0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-5000ppm, 0-10000ppm	0.001, 0.01, 0.1, 1ppm
C6H6	0-10ppm	0-1ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-5000ppm, 0-10000ppm	0.001, 0.01, 0.1, 1ppm
C7H8	0-10ppm	0-1ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-5000ppm, 0-10000ppm	0.001, 0.01, 0.1, 1ppm
C8H10	0-10ppm	0-1ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-5000ppm, 0-10000ppm	0.001, 0.01, 0.1, 1ppm
